Winglets

Subwoofer Array designed by Mauricio Ramírez (Magu)

Calculate delays for the Winglets sub array. Tool created to simulate sub behavior and line-array coverage. Sub array designed by Mauricio Ramírez (Magu).

Parameters

Subs in line Spacing (m) Desired coverage (°) Arc radius (m, optional) Horizontal steering (°) Speed of sound (m/s) Gradient frequency (Hz)

If you set a radius, coverage is recalculated; if left empty, radius is computed from coverage. End pairs are processed as gradient at the selected frequency: gap = 1/4 λ, inner sub inverted with extra delay. In addition, each end sub is duplicated as "Top Edge" (same position and same processing), and each middle sub is duplicated as "Top Middle Inverted" (same position, 180° rotation, inverted polarity, and delay +3.4 ms vs. its base) for SubMate export.

Results

#	On	X axis	Y axis	Lvl (dB)	Delay (ms)	Rot°	Polarity	Layer
